Nylofor 2D

Nylofor 2D is a complete professional fencing system that provides both high rigidity and security.


Benefits

Very high rigidity
The Nylofor 2D panels are extremely rigid due to the use of heavy welded mesh in conjunction with double horizontal wires.

High degree of security
Nylofor 2D is recommended as fencing for applications where security is crucial, resulting from the small mesh and the heavy wires.

Very high longevity
The coating technology  guarantees an extra high longevity. After galvanising an adhesion coating is applied for a perfect bond with the polyester coating of min. 100 micron.

Complete system
The Nylofor 2D system includes panels in different mesh apertures and heights, posts with adapted fixation systems and a large range of mesh and gates. All components guarantee a fast and professional installation.

Ideal for

Schools, play grounds, parks and sport grounds, public buildings, factories and workshops, airports and military sites, particularly suitable for the security of sport grounds

Technical Informations:

Mesh size: 200x50mm
Horizontal wire diameter:2x6mm and vertical wire diameter:5mm
Finish: galvanized then polyester coating
Color:  green RAL6005 ,white RAL9010,black RAL9005 and other color.
The panels are extremely rigid and secure due to the double horizontal wires.
The panels have vertical barbs of 30 mm on one side (top or at bottom).
Fence height Dimensions panels No. of reinforcements Post length
(mm) W x H (mm) per panel (mm)
1030 2500x1030 0 1500
1230 2500 x 1230 0 1700
1430 2500 x 1430 0 2000
1630 2500x1630 0 2200
1830 2500x1830 0 2400
2030 2500x2030 0 2600
2430 2500x2430 0 3200
